There are several possible reasons why a bar code scanner may not recognize a bar code

Bar code scanner is a common bar code reading equipment, also known as scan code gun, bar code scanning gun, with the function of reading bar code data, bar code is the strongest auxiliary equipment where it occurs! As long as it's a bar code, the bar code scanner will identify it. This is why some people ask: why my scanning gun will have a barcode that cannot be identified. But it's broken? Xiaobian tells you that it is not necessarily broken.

One possible cause:

1) The wire of the wired scanning gun is not properly connected;

2) The wire of the wired scanning gun is not properly connected to the computer;

3) The computer's power supply is insufficient so that the scanning gun cannot work;

4) Whether the USB port and PS/ port of the computer are normal;

5) The line of the wired scanning gun is broken;

6) The bald head or motherboard of the wired scanning gun is broken.

Wired barcode scanner has light but can't scan

Other possible reasons:

1) The scanning gun of PS/2 is connected to the mouse port; Great! (No compliments!)

2) The scanning gun of PS/2 is correctly connected to the keyboard port, but the scanning gun is not connected to the keyboard of PS/2, the scanning gun is not adjusted to not connect to the mode of PS/2 keyboard;

3) The scanning gun of PS/2 is connected to the conversion line of USB to PS/2, but the chip of the conversion line is not good, so it often fails to scan or has wrong codes;

4) The cursor is not in the scanning area during scanning, and the computer will occasionally pop up a window to change the position of the cursor during scanning;

5) The input method is not closed during scanning, which may result in no scanning or error code;

6) If the scanned code is not opened, all the code switches can be turned on;

7) The bar code does not meet the specifications, such as the lack of necessary blank areas, the contrast between bar and empty is too low, the width ratio between bar and empty is not appropriate;

8) The bar code surface is covered with transparent material, the reflectivity is too high, although the eyes can see the bar code, but the scanning gun can not read;

9) The scanned bar code is incomplete or seriously damaged;

10) Direct sunlight or light is too strong for the scanning gun to scan;

11) There is a problem with the interface transmission. The interface may be broken, or the line of the scanning gun may be broken;

12) If the Settings of the wired scanning gun are messed up, open the manual of the scanning gun and scan the factory setting bar code, which is usually "restore factory Settings", "ALL DEFAULT", "initial Settings", "restore default values" and so on;

13) The serial port number and baud rate of the serial port gun are not set properly;

14) Scanning the bar code is too far away or too close, the Angle is too big;

15) Can not scan a very fine bar code, the scanning accuracy of the general wired scanning gun is more than 5MIL, if your bar code is less than 5MIL, please buy a 3MIL wired scanning gun.
