Why can't the barcode just printed be scanned

I do not know whether you have encountered this situation, the bar code generated in the bar code generation software is normal, preview is normal, but when the barcode scan can not come out? There are many reasons why barcode scanning can not come out. Today, we mainly aim at this problem and summarize some reasons.

Bar code deformation, bar code is a relatively precise bar code symbol, all kinds of code have the corresponding ratio, in the process of bar code production of random deformation of the bar code, there will be the result of barcode can not be recognized.

2. The bar code is broken vertically, which generally occurs when the bar code printer prints bar code labels. The print head is broken and the carbon belt is wrinkled.

3. The width of the bar code blank area is insufficient. The left and right blank areas of the bar code must be at least 10 times the width of the narrow bar.

4 bar code and empty color collocation problem, bar code reading difference depends on the color of the bar, high reflectivity of the color will be identified as empty, low reflectivity of the color will be identified as a bar, generally, white blue bar code can be read, red black bar code can be read, yellow purple bar code can be read. Generally, the bar code with red bar on white background cannot be read, and the bar code with black bar on blue background cannot be read.

5. The barcode printing effect is not clear, usually because the medium does not match or the printing concentration value is set too low.

6. The barcode density is too high. The bar code density is determined by the module size. The smaller the module size, the higher the density. If the barcode density is too high, it is difficult to identify the scanning equipment with low recognition (resolution). The precision of printing equipment is also relatively high. So when doing barcode, also consider printing and scanning equipment, barcode density is not set too high.
